ADAS Testing
Advanced Driver Assistance Systems Testing
ADAS Testing
Siemens is fully equipped to perform all sorts of ADAS tests, from regulatory to development. Our dedicated team performs consumer tests for passenger vehicles: for example, those devised from the European New Car Assessment Program (NCAP). We are also fully equipped to perform all ADAS tests conforming to current United Nations Economic Commission for Europe (UNECE) regulations for trucks and buses, such as ECE Regulation 130 lane departure warning system (LDWS) and ECE Regulation 131 (advanced emergency braking system (AEBS). Additionally, all our ADAS activities are International Organization for Standardization (ISO) 10725 accredited.
We are fully accredited to assess the performance of ADAS according to globally recognized testing procedures, for example, those devised by consumer safety group Euro NCAP.
Equipment and Facilities
Our ADAS team is prepared with the best equipment for testing using Anthony Best Dynamics CBAR, SR60 Steering Robot, SR15 Steering Robot, SPT20 Pedestrian propulsion unit, Guided Soft Target, TrackFi V2V synchro. We use Oxford Technical Solutions (OxTS) 6 axis IMU RT3003 and RT3003X, OxTS DGPS Base Station and OxTS RT Range system for GPS guidance in our test vehicles and targets. We make use of the Aldenhoven Testing Center (ATC), which is an accredited Euro NCAP test track in Germany, compliant for all consumer testing plus ECE-130 and ECE-131 regulations.
Euro NCAP autonomous emergency braking testing
The Autonomous Emergency Braking (AEB) tests consist of two categories: Car to Car Rear scenarios and Vulnerable Road User tests. AEB tests in a Car to Car Rear scenario incorporate two elements: City Systems (AEB) and Inter Urban Systems (AEB and FCW). AEB tests regarding Vulnerable Road Users include both pedestrian scenarios and cyclist scenarios. Our dedicated ADAS team can perform all consumer AEB tests, including development tests that may require alternative specifications, from different target offsets to diverse light conditions.
Euro NCAP lane support system testing
We perform Lane Support Systems (LSS) tests in accordance with Euro NCAP protocols that consist of the following elements: Emergency Lane Keeping (ELK), Lane Keeping Assist (LKA) and Lane Departure Warning (LDW). For these tests we make use of the Euro NCAP accredited Aldenhoven Testing Center. This test track includes all required features; such as real road edges (RRE), dashed, solid and fully marked lanes to perform all Euro NCAP Lane Support Systems tests.
Future ADAS protocols
As vehicle technology progresses, so does the need for consumer testing of the technologies. Because our ADAS Safety Expert is a member of the Euro NCAP working groups, we are always involved in changes and therefore are able to offer customers ADAS tests that are already compliant with future protocols. This gives our customers the opportunity to consult us regarding future protocols, but also to test vehicles, systems and components in early development phase that can benefit from consulting.
Our Dedicated ADAS team
Our ADAS (Advanced Driver Assistance Systems) team consists of technical specialists that are solely dedicated to ADAS activities and work across several countries and test tracks. They are active throughout the entire year, which makes it possible to have a flexible agenda for our customers. Joining the team of technical specialists are our engineers, who support where needed. Our test engineers perform pre-NCAP assessments, benchmark testing and official testing according to all ADAS official protocols. Additionally help can be provided in the early phase of development with whole vehicle, component and system development testing, both on and off the test track. Our specialists are available for consultancy regarding test methods and scenario development.
Test targets
We are fully equipped with the latest test targets used for consumer and certification testing. Our Global Vehicle Target is a controllable soft vehicle target on a self-propelled GPS guided platform (accurate to 1cm). Upon impact the target foam body separates into lightweight parts, avoiding damage to the vehicle under test and allowing quick reassembly between test runs (assembled in approx. 10 minutes). The Global Vehicle Target is capable of a maximum speed of 100 km/h and is therefore up to the latest test requirements. Because the target contains the same radar, lidar and visual attributes of an M1 passenger vehicle, it should be seen as such by the vehicle under test. For VRU assessment we use 4active articulated adult and child dummies as well as adult bicyclist dummy. These dummies are designed with humanlike radar cross section, infra-red and visual properties and are fully impactable and rebuildable.
UNECE heavy duty testing
Additional to consumer testing, we are an RDW accredited laboratory authorized to carry out regulatory testing for UNECE of ECE-R130 (Uniform provisions concerning the approval of motor vehicles with regard to the Lane Departure Warning System (LDWS)) and ECE-131 (Uniform provisions concerning the approval of motor vehicles with regard to the Advanced Emergency Braking Systems (AEBS)). Both regulations concern assessment of heavy duty vehicles (trucks and buses).
