Simcenter STAR-CCM+ Aerodynamics (incompressible and compressible)

Prebuilt Simcenter STAR-CCM+ simulations enable students to interactively learn about the concepts taught in class by using a handful of buttons. Simcenter STAR-CCM+ allows for changes in geometry, material properties, and flow rate in a few clicks so that students can see how these changes affect the physics in a system. The scenes also update live during the run allowing students to see things like vortex shedding happen in near real time.

This includes:

  • Incompressible flow:
    • Basic Shapes
    • Backward/Forward Facing Step and Concave/Convex Corner
    • 2D Cars
    • 3D race car
  • Compressible flow:
    • Basic Shapes
    • Convergent divergent nozzles
    • Backward/Forward Facing Step and Concave/Convex Corner

The sims are quick to run as most are built in 2D or axisymmetric so they can be run on laptops:
- Incompressible flow: 5 mins
- Compressible flow: 45 mins

First time signing up? Please be sure to confirm your opt-in with the email you'll receive shortly.

Please download all the files and extract them to a common directory.

Compila il modulo per accedere alla risorsa

Spiacenti,

si è verificato un errore con l'inoltro della pagina. Riprovare.

Thank you, your information has been received.

Download the Simcenter STAR-CCM+ Aerodynamics Curriculum Package

First time signing up? Please be sure to confirm your opt-in with the email you'll receive shortly.

Please download all the files and extract them to a common directory.
