Blade Cooling

Simcenter provides a paradigm shift in simulating aerodynamics and heat transfer for gas turbines. Our multi-physics and timescales capabilities, combined with tools designed to mesh the most complex geometries, give you more accurate answers and greater engineering insight. Simulate and predict external aerodynamics, internal cooling, solid temperatures and even solid stresses in one package.

Simcenter provides a paradigm shift in simulating aerodynamics and heat transfer for gas turbines. Our multi-physics and timescales capabilities, combined with tools designed to mesh the most complex geometries, give you more accurate answers and greater engineering insight. Simulate and predict external aerodynamics, internal cooling, solid temperatures and even solid stresses in one package.

Learn More

Turbine blades must perform reliably under intense operating conditions. Physical testing is expensive and time-consuming, and monitoring conditions inside the solid blade is impossible.

Our solutions enable you to simulate and predict the performance of full complexity blades by including all geometric features and solving for both flow and solid temperatures.  Reduce your development costs by rapidly evaluating multiple designs in a virtual environment, before any physical testing takes place.

Simcenter’s portfolio of tools give you the ability to:

  • Improve blade aerodynamic performance by simulating airflow both around and within the blade.
  • Understand the impact of design changes on cooling flow and blade temperatures.
  • Reduce reliance on simplified models and increase confidence by simulating the full complex blade geometry and including all essential physics.
  • Predict thermal stress and ensure maintenance targets are met.
  • Speed up design cycles and reduce development costs via automation, multi-physics CFD and design exploration.
Success story présentée

B&B-Agema

B&B-AGEMA uses Siemens Digital Industries Software solutions for design space exploration

Simcenter STAR-CCM+ helps energy consultancy firm improve gas turbine blade cooling

En savoir plus

Webinaire à la demande | 46 minutes

High fidelity aerodynamic simulation for gas turbine design

Gas turbine design

Learn how Siemens Energy create high fidelity turbine simulations by combining results from different disciplines, to create efficient and reliable gas turbine designs.

Regarder le webinaire

Fonctionnalités de la solution

Explore the key areas of this solution.
