Engine design controls

Internal combustion engine system simulation

Develop internal combustion engine systems and controls.

Accurate physical engine and component models

Evaluate, design and optimize complete internal combustion engine systems, from air management and combustion to exhaust after-treatment and engine controls, by using accurate physical engine and component models. The capabilities for internal combustion engine simulation are developed in close collaboration with IFP Energies nouvelles.

By applying a system simulation approach using Simcenter, you can now study integration with fuel injection subsystems, engine thermal management, electrical devices, powertrain and various other components, as well as adapt model definitions to a wide range of scenarios. Simcenter allows you to analyze the impact of advanced technology choices and gives you a powerful toolset to investigate alternative engine architectures and concepts.

Is your powertrain roadmap digital enough?

Next Euro 7 and Tier 4: Addressing the challenges that lay ahead. Balancing/Optimizing conventional powertrain design into an electrified powertrain.

Watch webinar

Internal combustion engine system capabilities

Air path & charging

Develop innovative air path architectures, including actuators, charging and cooling systems, and rapidly analyze their impact on gas management, combustion and emissions. In addition to a broad set of component models that enable you to design advanced air path systems and study the engine performance, Simcenter provides powerful application-oriented analysis tools, a Simulink interface, and generic co-simulation to allow integration with computational fluid dynamics (CFD) software.

Simcenter software displaying gas management, combustion and emissions.

Combustion

Offer your customers better engine response and lower fuel consumption. Simcenter supports the design and optimization of conventional and innovative combustion processes as well as the adoption of alternative fuels. You can optimize engine parameters, such as spark advance, turbulence, lambda control or injection split for different fuel types and assess the benefits in terms of efficiency, torque production and emissions.

Simcenter Flomaster software visual.

Engine controls

Address the growing complexity of engine control strategies using the multiphysics plant modeling capabilities of Simcenter. Engine control engineers in charge of controls design, validation (offline or real-time) and calibration can use the state-of-the-art Simcenter engine, after-treatment and powertrain models at every development stage. An efficient Simulink interface and straightforward export workflows ease the integration of the models in your processes.

A visual from the Simcenter Amesim software.

Exhaust after-treatment

Meet emission standards including Real Driving Emissions (RDE) by optimizing exhaust systems and associated control strategies. Simcenter allows you to accurately model and analyze the conversion of nitrogen oxides (NOx), carbon monoxide (CO), hydrocarbons (HC) and soot filtration. You can work on exhaust system components and controls and integrate the after-treatment system in a vehicle configuration in order to evaluate the emissions for driving cycles.

Simcenter software visual.
Case study

École Centrale de Lyon

Siemens Digital Industries Software solution enables École Centrale de Lyon students to improve engine intake and exhaust system performance.

Engineering school uses Simcenter Amesim to gain five horsepower in racecar engine
Case Study

Engineering school uses Simcenter Amesim to gain five horsepower in racecar engine

Company:École Centrale de Lyon

Industry:Automotive & transportation

Location:Lyon , France

Siemens Software:Simcenter 3D Solutions, Simcenter Amesim

Read

Explore internal combustion engine system products

Dashboard of thermo-fluid system simulation using Simcenter Flomaster
Simcenter

Simcenter Flomaster software

Simcenter Flomaster offers a comprehensive simulation toolset for designing, commissioning and operating thermo-fluid systems. It can connect to PLM, CAD, simulation and industrial IoT to embrace digital transformation.
