Automotive Mold, Tool & Die

Automotive Mold, Tool & Die

Our digital manufacturing solutions help maximize business performance by improving manufacturing planning collaboration; defining and optimizing proposed manufacturing processes; designing and manufacturing high-performance tooling; supporting effective communication with production and shop floor systems; and monitoring and controlling quality. With all these systems and processes connected in a digital thread, greater levels of efficiency are achieved by designing, engineering and simulating products virtually.

Our digital manufacturing solutions help maximize business performance by improving manufacturing planning collaboration; defining and optimizing proposed manufacturing processes; designing and manufacturing high-performance tooling; supporting effective communication with production and shop floor systems; and monitoring and controlling quality. With all these systems and processes connected in a digital thread, greater levels of efficiency are achieved by designing, engineering and simulating products virtually.

Automotive Mold, Tool & Die

Learn More

Digital manufacturing helps you eliminate potential issues earlier and optimize throughput by enabling greater collaboration in a Model-Driven Program Execution environment.

Create part manufacturing plans with our solutions that enable planning and collaboration between manufacturing, engineering and suppliers. As a result, you can use captured process parameters to produce highly accurate quotes and use quotes to quickly prepare and update detailed manufacturing plans. You can also manage the manufacturing plan data under full revision and configuration control in a secure environment.

For the design and manufacture of Die and Mold tooling, our solutions help you streamline the CAD/CAM/CNC process chain to reduce tool cost and deliver high-quality parts on time. Our solution can deliver released plans to production by connecting the managed PLM environment for design and manufacturing planning directly to shop floor systems.

Greater efficiency is achieved using our solution for virtual commissioning of production to identify and correct production and quality issues in a production digital twin prior to launch. Finally, monitor and control quality with our solution to gain a comprehensive view of the factory operation, identifying production issues earlier and resolving them quicker.

Automotive Mold, Tool & Die

On-Demand Webinar | 30 minutes

Fluid Flow Topology Optimization

Optimization of a part for fluid flow efficiency using Star CCM+

Topology Optimization like you’ve never seen

Watch the webinar

Solution capabilities

Explore the key areas of this solution.

Additive Manufacturing

Create revolutionary products using our integrated additive manufacturing software. Design, simulate, prepare, print, and validate prototype or production parts on a wide range of 3D printing equipment.

Bill of Materials Management

By providing a common source of BOM information across your organization that is flexible and scalable, you can meet and exceed the market demand for more innovative and varied product offerings.

CNC Machining

Efficiently program any job – from production machining and mold manufacturing to 5-axis milling and automated robotic operations – using one computer-aided manufacturing (CAM) software.

Composite Manufacturing

Address the complex and specialized composite manufacturing processes through an intelligent design-to-manufacturing composite solution that is fully integrated into commercial 3D CAD systems.

Design Validation

Ensure proper mold cooling through thermomechanical simulation of manufacturing process. Optimize the design of molds for manufacturing of composites through simulation of curing and complete mold process performance.

Die Design Validation

Design, simulate and optimize jigs and tooling fixtures through structural analysis, vibration analysis and topology optimization. Reach targets like minimum stiffness, optimal weight or avoiding unwanted vibration.

Manufacturing Process & Data Management

Connect people, systems and machines through manufacturing process planning using a digital thread to accumulate knowledge and continuously improve operations.

Manufacturing Quality Planning

Integrate quality parameters during product design, manufacturing planning and production to eliminate costly product quality issues.

Progressive Die Design Validation

Prevent damage and cracks in dies through thermomechanical simulation of damage initiation and propagation for improved run rates and capacity utilization.
